Always!
¾ Read all instructions before installing any Havis-Shields Equipment Corp products.
¾ Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
¾ Use hardware provided with install kit
INSTALLATION:
• Remove front passenger seat bolts. Loosen but do not remove rear bolts.
Telescoping
Pole Assembly
Note: When installing C-TCB-24 into Extended Cab or Crew Cab pick-ups, the air duck on
the passenger side floor must be cut out or completely removed to install.
• Slide base of the pole support assembly under the seat base brackets.
• Align the holes of the seat base, the pole support assembly and floor holes. Replace
front seat bolts. Firmly tighten all seat bolts without over tightening.
• Attach lateral brace arm assembly to the pole support assembly with 5/16” x 1” Hex
head bolt, washer and nylock nut.
• Secure lateral brace arm to side of the transmission hump using ¼” x ¾” Hex head
lag bolts.
Note: When mounting side support brace to floor of vehicle, be sure to check for obstructions prior to
drilling or lag bolting to floor.
•
Tighten the screw that attaches the brace arm to the pole support assembly last.
• Tighten down factory passenger seat bolts and 5/16-18-nylock nut holding side
support brace to pole support assembly.
• Mount optional C-3090, computer-mounting platform, to telescoping pole assembly
using hardware and instructions provided with C-3090.
Pole Support
Assembly
