VAC-1000HD User’s Guide
16
5.3 Typical application
Blu-ray disc player
DVI/HDMI
HDCP output
:
Analog audio output
LC monitor
LC monitor
Projector
Speaker
DVI/HDMI
HDCP output
10 distribution
Projector
DVI/HDMI
HDCP output
DVI/HDMI
HDCP output
DVI/HDMI
HDCP output
HDMI signal distributor
VAC-1000HD
ON
OFF
DISTRIBUTIO N AMPLIFIER for HDMI VAC-1000HD
POWER SIGNAL
[Fig. 5.5] Source and sink devices are connected
