VAC-1000HD User’s Guide
10
2 Product outline
The VAC-1000HD is an HDMI distribution amplifier for distributing digital video and audio signals to 10
outputs.
Since signals can be distributed to multiple devices that have the HDMI input connector, the VAC can be used
for multiple systems of HD images, production lines, and others. An L/R stereo audio output is provided, and
only the embedded digital audio input is converted into an analog stereo signal for the stereo analog audio
outputs.
The HDMI input has an automatic compensation circuit while the HDMI output has a manual one, and they
are able to minimize signal degradation caused by cable extension.
10
distribution
EDID
emulator
Input EQ
VAC-1000HD
D/A
conversion
Analog audio
L/R unbalanced
outputs １
Digital video and audio
HDMI DVI
outputs １０
Output EQ
Max. 50 m/
164.04 feet Max. 50 m/
164.04 feet
Video/Audio
Audio
Digital video and audio
HDMI DVI
outputs
１
[Fig. 2.1] Video and audio signals I/O diagram
