Page 22.
GM Torque Specifications
QTY Fastener Description Torque (ft-lb or in-lb) Torque (N·m)
3 Differential mounting Bolt 59 ft-lbs 80 N·m
1 (on each side) Upper control arm bolt 44 ft-lbs plus 90° 60 N·m plus 90°
1 (on each side) Wheel driveshaft nut 199 ft-lbs 270 N·m
1 (on each side) Stabilizer arm bolt 103 ft-lbs 140 N·m
1 (on each side) ABS sensor bolt 80 in-lbs 9 N·m
1 (on each side) Brake line bracket bolt 80 in-lbs 9 N·m
4 Fuel tank strap bolt 37 ft-lbs 50 N·m
3 Driveshaft coupling bolt 67 ft-lbs 91 N·m
4 U-joint strap bolt 18 ft-lbs 24 N·m
4
Chassis stiffening bracket
(Camaro convertible)
43 ft-lbs 58 N·m
4
Chassis stiffening bracket
(Camaro coupe)
18 ft-lbs 25 N·m
5 (on each side) Rear wheel lug nut 122 ft-lbs 165 N·m
Torque Specifications specific to the LPE Camaro 9.5” Differential
QTY Fastener Description Torque (ft-lb or in-lb) Torque (N·m)
10 Cover plate bolts 55 ft-lbs 74 N·m
4 Differential bearing bolts 74 ft-lbs 100 N·m
1 Fill hole plug 18-29 ft-lbs 25-40 N·m
1 Drain hole plug 18-29 ft-lbs 25-40 N·m
6 (on each side) Halfshaft flange screw 55 ft-lbs 74 N·m
76. The recommended break in period is light
duty usage for the first 500 miles. If this is not
possible then use a break-in schedule of ten (10)
acceleration runs from 25-65 MPH with a cool
down time between each run. The reasoning for
this is to ensure slight wear on the differential
gear without overheating the unit. Be sure to
avoid extended runs at high power and load, as
well as high sustained vehicle speed during the
break in period of 500 miles.
77. The installation of your 9.5” differential is
complete.
