Lingenfelter L380xx1410 Lingenfelter Camaro Cast 241 MM Aluminum Differential 2010-12 v1.9 User Manual

Page 17

background image

Page

52. Using a 32mm socket and ratchet, install

the axle nuts. Torque the nut to 199 ft-lbs.

53. Using a 18mm socket and ratchet, install

the stabilizer arm bolt. Torque the bolt to 103

ft-lbs.

54. Using a 10mm socket, ratchet and

extension, install the ABS sensor. Torque the

bolt to 80 in-lbs.

55. Using a 10mm socket and ratchet, install

the brake line bracket bolt. Torque the bolt to 80

in-lbs.

16.
