Lingenfelter L380xx1410 Lingenfelter Camaro Cast 241 MM Aluminum Differential 2010-12 v1.9 User Manual
Page 13
Page
37. Remove the OEM vent hose from the top
of the OEM differential.
36. Using a 18mm socket and ratchet, remove
the three (3) mounting bolts (the two front bolts
shown by the arrows and the rear bolt not
pictured) then remove the differential.
NOTE: Support the differential with a jack to
relieve weight from the bolts so they can easily
slide out.
38. Install the supplied vent hose (PN:
5283K13) and Oetiker clamp (PN: 52545K71)
onto the vent fitting of the LPE differential.
NOTE: The adjacent picture is for illustration
purposes only.
39. Lift the new differential into place with the
jack. Be sure all bushings are set and secure in
the casing.
12.
