Lingenfelter L320061410 Lingenfelter High Capacity Intercooler Heat Exchanger Camaro SS & ZL1 v1.1 User Manual

Page 5

Page 4.

6. Remove all six of the plastic retainer clips

from the top of the front facia marked by

yellow arrows using a flat head screwdriver.

Using a 10 mm socket, loosen the two

corner screws marked by the blue arrows.

7. Remove the bottom two screws of the front

facia using a 10 mm socket.

5. For ZL1 Camaro, please skip to step 6.

On the Camaro SS remove the five screws

using a 10 mm socket and the five fasteners

using a flat head screw driver on the inner

wheel well liner, then remove the wheel well

liner.

8. If the Camaro is equipped with fog lights,

then disconnect the two connectors for the

fog lights, one on each side.
