Scale Basic 4.2E
Reference
61
Alt units - Gross weight
62
Alt units - Tare weight
63
Alt units - Net weight
64 Gross
Weight
65 Tare
Weight
66 Net
Weight
ID Registers
Each ID record in memory has 6 registers. The register data for an ID is available when it is
"opened" (instructions Get id, Make id, functions Open id and Open new). The register data is
written to an ID record when it is "closed" (instruction Write id and function Close id). The Id
Number register contains the ID of the currently open ID record. This register is read only, it
should not be written to.
Reg. Number Register Name
67
Id Register 1
68
Id Register 2
69
Id Register 3
70
Id Register 4
71
Id Register 5
72
Id Register 6
73
Id Number (read only)
Other Registers
The Pulse register contains the number of pulses received on TTL input 6. The Rate register
contains the number of pulses received on TTL input 6 in 1 second (pulses / second).
The True and False registers are used by the Setpoint Monitors to enable triggering on condition
codes. If a setpoints upper register is set to true, and the lower register is set to Motion, then the
setpoint will trigger when the scale is in motion.
Reg. Number Register Name
55
Rate - calculated from TTL input 6
57
Pulse - from TTL input 6
115
True - used in Setpoint Monitors
116
False - used in Setpoint Monitors
118
Time – used to copy time to reg x
119
Date - used to copy time to reg x
120
Stime – used to copy stored time to reg x
121
Sdate – used to copy stored date to reg x
