CRAFTSMAN HI WHEEL SELF-PROPELLED ROTARY MOWER MODEL 247.88110
M
u
REF.
NO. PART
NO. DESCRIPTION
REF.
NO. PART
NO. DESCRIPTION
1 710-121 Hex Scr. ’/2-20 X .75" Lg. Special 37 11996-347 Spacer Plate Ass'y.
2 736-114 Internal Lockwasher ’/ 2 " Scr.* 38 710-409 Hex Scr. 5/16-24 x 1.75" Lg.*
3 748-108 Flange Bearing .503" I.D. 39 754-121 "V"-Belt ’/ 2 " X 31.8" Lg. (Drive
4 748-136 Pinion Gear .50" I.D. 14 Teeth Belt)
5 7146 Pinion Shaft 40 756-205 Two Step Engine Pulley
6 748-110 Flange Bearing .630" I.D. 41 736-235 Flat Washer .406" I.D. x 1.25" O.D.
7 8187-347 Gear Box Cover X.164
8 710-148 Hex Washer Hd. F-Tapp. Scr. 42 736-217 Spring Lockwasher %" Scr. Heavy
#8-32 X .38" Lg.* Duty
9 748-135 Bevel Gear .62" I.D.—28 Teeth 43 710-152 Hex Scr. %-24 x 1.00" Lg. Heat
10 711-180 Control Rod Treated
11 711-179 Adjustable Ferrule 44 710-528 Hex Scr. 5/16-18 x I’A" Lg.*
12 8331 Pull Bar Assembly 45 736-119 Spring Lockwasher 5/16" Scr.*
13 8189 Gear Box 46 712-130 Hex Inserted Locknut %-16 Thd.
14 710-289 Hex Scr. ’/ 4-20 X .50" Lg.* 47 8324-347 Belt Guard
15 736-329 Spring Lockwasher ’A" Scr.* 48 736-119 Spring Lockwasher 5/16" Scr.*
16 710-252 Hex Scr. '/ 4-20 X .75" Lg.* 49 712-267 Hex Nut 5/16-18 Thd.*
17 8348 Drive Shaft 50 8298 Idler Bracket Ass'y. with Brake Shoe
18 748-110 Flange Bearing .630" I.D. 51 756-370 Idler Bearing Ass'y.
19 710-421 Set Scr. 5/16-18 X .25" Lg.* 52 736-300 Flat Washer .385" I.D. x .87" O.D.
20 715-247 Spring Pin Spirol 3/16" Dia. x X .06
1.00" Lg. 53 7353 Belt Clip
21 7120 Nylon Pinion 54 712-158 Hex Center Locknut 5/16-18 Thd.
22 711-415 Clevis Pin .375" Dia. 55 9373 Control Rod
23 736-300 Flat Washer .385" I.D. x .87" O.D. 56 732-137 Extension Spring
X.06 57 732-158 Blade Tension Spring
24 714-121 Cotter Pin 5/32" Dia. x 1.00" Lg.* 58 754-109 "V"-Belt ’/2 X 43" Lg. (For Blade)
25 736-329 Spring Lockwasher ’A" Scr.* 59 738-234 Shoulder Scr. .500" Dia. x .295
26 712-287 Hex Nut ’A-20 Thd.* 60 736-108 Flat Washer .510" I.D. x .750" O.D.
'¿/ 1 1 0 0 / - J 4 / Stop—Drive Plate X .033
28 711-169 Collar %" I.D. 61 9371 Brake Lever
29 736-108 Flat Washer .510" I.D. x .75" O.D. x 62 712-922 Hex Jam Nut ’/2-20 Thd.
.033 63 736-921 Spring Lockwasher ’/ 2 " Scr.*
30 8772-347 Belt Guard 64 9925 Sheave Ass'y.—4" Dia. (Blade
31 712-287 Hex Nut ’/ 4-20 Thd.* Spindle)
32 736-329 Spring Lockwasher ’A" Scr.* 65 8279-347 Frame Ass'y.—Comp.
33 748-226 Hex Flange Bearing .503" I.D. 66 736-147 Extern Lockwasher #10
34 8774-347 Bottom Frame Ass'y- 67 10523-347 Top Drive Frame Ass'y.
35 9927 Sheave Ass'y-—5.50 x .50 68 736-105 Belleville Washer %" I.D.
36 714-229 #2 Woodruff-—Key 3/32 x ’/ 2 " Dia.
Hardened
^Standard Hardware Items—May Be Purchased Locally.
