1. I NTRODUCTION W HEATHEART - P OST P OUNDER
1.3. M AST A SSEMBLY S2000 M ODEL
8 IM15 R1
1.3. MAST ASSEMBLY
The mast assembly mounts on the frame assembly pivot arm, and contains the
mast cylinder, ballast box and hammer, and hammer guard. Figure 1.2 shows the
major features of the assembly.
Figure 1.2 Mast Assembly Detail
MAST CYLINDER
BALLAST BOX
HAMMER GUARD
MAST CYLINDER
BALLAST BOX COVER
HUGGER BRACKET BOLT HOLES
PIVOT ARM BOLT HOLES
HYDRAULIC CONNECTOR
TOP HAMMER STOP
BOTTOM HAMMER STOP
