Wheatheart S2000 Post Pounder - Manual (Page 34)

3. A SSEMBLY W HEATHEART - P OST P OUNDER
3.3. I NSTALLING THE PTO K IT S2000 M ODEL
34 IM15 R1
3.3.5. F
ILLING THE
H
YDRAULIC
T
ANK
For general operation, Wheatheart recommends an ISO viscosity 32 heavy duty
industrial hydraulic mineral oil.
After all PTO kit components have been installed correctly, fill the hydraulic tank
with hydraulic oil as follows:
1. Remove the hydraulic tank cap.
2. Add
hydraulic oil to the hydraulic tank, but do not overfill (leave space at the
top of the tank).
3. Slowly extend and retract all hydraulic cylinders until air is displaced from the
hydraulic system.
4. Add additional fluid to make up for air displaced from hoses, but do not
overfill the tank.
5. Replace and tighten the tank cap.
