Pto kit – Wheatheart S2000 Post Pounder User Manual
Page 10
1. I
NTRODUCTION
W
HEATHEART
- P
OST
P
OUNDER
1.5. PTO K
IT
S2000 M
ODEL
10
IM15 R1
1.5. PTO KIT
The optional PTO Kit (Part Number 2311153) provides the S2000 Post Pounder
with a hydraulic system powered by a hydraulic pump that connects to a tractor
PTO shaft.
The kit contains:
• a hydraulic pump and storage post
• a hydraulic tank and support brackets
• a hydraulic oil filter, filter head, and support bracket
• a hydraulic hose
The PTO Kit’s hydraulic pump provides adequate system pressure when
installed and connected to a 540 RPM PTO.
Installation requires modifying an existing hydraulic hose and installing an
additional hose.
Figure 1.4 PTO Kit Major Parts
HYDRAULIC TANK
PTO PUMP
OIL FILTER
