3. A SSEMBLY W HEATHEART - P OST P OUNDER
3.3. I NSTALLING THE PTO K IT S2000 M ODEL
30 IM15 R1
3.3.2. I
NSTALLING THE
PTO K
IT
H
YDRAULIC
T
ANK
1. Position the hydraulic tank support bracket on the frame assembly (Figure
3.9 shows the mounting location).
2. Connect the hydraulic tank support bracket to the frame assembly using the
supplied U-bolt (see Figure 3.11).
Figure 3.11 Installing the Hydraulic Tank Support Bracket
3. Place the hydraulic tank in the hydraulic tank support bracket with the lowest
of the two hydraulic connectors facing the three-point hitch, and secure the
tank with the tank strap using the two hex bolts and 5/16 nylock nuts (See
Figure 3.12).
1/2” NYLOCK NUTS
HYDRAULIC TANK BRACKET
U-BOLT
