522D
MATERIAL HANDLER
Item
Part No.
Qty.
Description Of Part
9109-5029
Ref
ENGINE ASSY, (includes all items on
page 5-4 except items 45, 46 & 49 thru
53, all items on page 5-5 except items
46, 47 & 48 and all items on page 5-6)
1
8319-1021
13
HEX HD CAPSCREW, M10X1.5X30
2
8319-1013
16
LOCKWASHER, M10
3
9108-6131
1
TUBE SUPPORT
4
9133-6003
1
TUBE SUPPORT
5
8856-1109
3
WASHER, 3/8
6
8319-1006
1
HEX HD CAPSCREW, M10X1.5X40
7
8319-1005
2
HEX HD CAPSCREW, M10X1.5X45
8
8471-2738
2
SPLIT FLANGE CLAMP
9
8320-1135
4
HEX HD CAPSCREW, 7/16-14X1-1/2
10
8855-1012
4
LOCKWASHER, 7/16
11
8855-1010
2
LOCKWASHER, 5/16
12
9002-8660
2
INSULATED HOSE CLIP
13
8850-1005
2
HEX NUT, 5/16-18
14
2486-1170
3
SUPPORT CLAMP
15
8820-1018
2
HEX HD CAPSCREW, 5/16-18X3/4
16
9109-1001
1
CLAMP SUPPORT
17
9136-3022
1
JUMPER WIRE
18
9108-6055
1
EXHAUST TUBING
19
9133-5011
1
STARTER RELAY ASSY, (includes the
following items)
7738-3377
1
RELAY
9133-1014
1
RELAY MOUNTING PLATE
8821-1028
2
SOCKET HD CAPSCREW, #10-24X1/2,
GR8
8850-1612
2
HEX NUT, #10-24
8856-1105
2
FLAT WASHER, #10
8855-1007
2
LOCKWASHER, #10
20
9114-3314
1
WATER TEMPERATURE SENDER
21
8871-1385
1
REDUCER BUSHING
22
8856-1108
1
WASHER, 5/16
Item
Part No.
Qty.
Description Of Part
23
8319-1011
1
LOCKWASHER, M8
24
8319-1007
1
HEX HD CAPSCREW, M8X1.25X16
25
8594-1016
1
SUPPORT CLAMP
26
9108-3503
1
ALTERNATOR, (includes item 27)
27
9108-3504
1
REGULATOR
28
9108-3481
1
NEGATIVE BATTERY CABLE
29
8319-1004
2
HEX HD CAPSCREW, M12X1.75X30
30
8319-1010
2
LOCKWASHER, M12
31
9108-3482
1
POSITIVE BATTERY CLAMP
32
8856-1111
1
WASHER, 1/2
33
9114-3122
1
SUPPORT CLAMP
34
9002-7187
1
TY-RAP
35
9108-3456
1
STARTER, (torque mounting screws to
35 ft. lbs.)
36
8871-1284
1
PIPE PLUG, 3/4
37
9020-5792
1
CUSHION CLAMP
38
9139-3003
1
TUBE ASSY
39
9108-3106
1
O-RING
40
9108-4162
1
FAN/ALTERNATOR BELT
41
9108-4001
1
OIL FILTER ELEMENT
42
8866-1384
1
HEX PLUG, 3/8 TUBE
43
9108-3218
1
FUEL FILTER
44
8348-3497
2
HOSE CLAMP
45
11"
FUEL LINE HOSE, 3/8
46
8820-1001
2
HEX HD CAPSCREW,1/4-20X1/2, GR5
47
8856-1107
2
FLAT WASHER, 1/4 2
48
8855-1009
2
LOCKWASHER, 1/4
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE FOR
SERVICE.
5-5
ENGINE & ATTACHING PARTS
(9109-5029) Engine Right Side View - 522D
Starting Serial No. 0277086 thru 0277119
Original Issue 8-99
Revised 5-16-00
DS
* Removed Engine Filter Kit.
