522D-524D
MATERIAL HANDLER
HYDRAULIC COMPONENTS
(9116-3027) Sway Cylinder Valve
Starting Serial No. 0277001
Original Issue 1-98
Item Part No. Qty. Description Of Part
9116-3027 1 SWAY CYLINDER VALVE ASSY
(includes items 1, 2, 3 & 5)
1 9116-4061 2 VALVE CARTRIDGE
2 9116-4056 2 VALVE SEAL KIT
3 9116-4062 1 PISTON
4 8859-1012 2 O-RING
5 1 VALVE BODY (not sold separately,
order P/N 9116-3027)
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE FOR
SERVICE
10-13 JH
