7
Broan Elite 61000/61000EX
A flawless look. A lasting impression.
Beautiful stainless steel construction in a wall mounted design.
• Seamless corners for easy cleaning.
• Concealed three-speed slide control.
• Heat Sentry
™
detects excessive heat
and adjusts blower speed to high
automatically.
• The 61000EX models are designed to
operate with the Broan Elite External
blowers, providing a choice of four
Exterior models: 600, 900, 1200 or 1500
CFM, or four In-Line models: 280, 600,
800 or 1100 CFM.
• Two 20-watt (four in 48") halogen
lamps included (one level).
• Available in 30", 35
7
⁄
16
" (90 cm)
or 48" sizes.
• Ducted/non-ducted telescopic flues fit
8' to 9' ceilings.
• Convertible to ducted or non-ducted
operation.** (excludes 48" model)
• Easily removable, dishwasher-safe,
stainless steel grease filters.
• Optional ducted flue extension for
up to 10' ceilings.
Chimne
y
Hoods
NOTE: Units using flue
extensions are for ducted
applications only.
C MIN
C MAX
CD
CW
613004
25
5
⁄
8
"
45
1
⁄
2
"
6
5
⁄
8
"
9
1
⁄
4
"
619004
25
5
⁄
8
"
45
1
⁄
2
"
6
5
⁄
8
"
9
1
⁄
4
"
619004EX
22"
37"
10
3
⁄
8
"
12
3
⁄
4
"
614804
22"
37"
10
3
⁄
8
"
12
3
⁄
4
"
614804EX
22"
37"
10
3
⁄
8
"
12
3
⁄
4
"
Range Hood Specifications
Options & Accessories
DUCT
FLUE
NON-DUCTED
WIDTH INTERNAL EXTERNAL
BLOWER
VOLTS
AMPS
CFM CONNECTION EXTENSION*
FILTER
30"
613004
Internal
120
3.1
450
6" RD
RFX6104
ROUNDFILTER
35
7
⁄
16
"
619004
Internal
120
3.1
450
6" RD
RFX6104
ROUNDFILTER
48"
614804
Internal
120
6.3
900
8" RD
RFX6104EX
35
7
⁄
16
"
619004EX External†
120
0.5***
†
8" RD
RFX6104EX
48"
614804EX External†
120
0.8***
†
8" RD
RFX6104EX
* Optional ducted flue extension for 10' ceiling—extensions over 10' have up to a 14-week order time.
** Requires a non-ducted filter kit, purchase separately. Round filter or SB08999736.
*** Hood amps w/o blower, for total system amps, combine hood w/ External blower amps.
†
External blowers sold separately.
