RM60000 Series
High
P
erf
ormance
Hoods
Ten HVI certified, ducted blower options
INTERNAL EXTERNAL*
EXTERIOR IN-LINE
CFM Model CFM Model CFM Model
1200 RM326H 1500 336 1100 HLB11
600 RM325H 1200 335 800 HLB9
900 332H 600 HLB6
600 331H 280 HLB3
NOTE: Purchase blower separately. See pages 42 and 43.
* External blower models require Rough-In Kit model 332KR.
Range Hood Specifications Options & Accessories
WIDTH
STAINLESS
STEEL
LAMPS*
HALOGEN HEAT+ VOLTS AMPS++
ALUMINUM
FILTER
BAFFLE
FILTER
30" 643004 Qty. 2 Qty. 2 120 3.8 Included RBF30
36" 643604 Qty. 2 Qty. 2 120 3.8 Included RBF36
42" 644204 Qty. 3 Qty. 2 120 4.2 Included RBF42
48" 644804 Qty. 3 Qty. 2 120 4.2 Included RBF48
* Lamps not included. Halogen are 50 watt, PAR 20; heat lamps are 175 watt, infrared PAR 38.
+ Optional backsplash is recommended when using infrared heat lamps.
++ Hood amps without blower; for total system amps combine hood and blower amps.
Range Hood Specifications Options & Accessories
WIDTH
STAINLESS
STEEL
LAMPS*
HALOGEN HEAT+ VOLTS AMPS++
ALUMINUM
FILTER
BAFFLE
FILTER
30" RM603004 Qty. 3 Qty. 2 120 5.4 Included RBF6030
36" RM603604 Qty. 3 Qty. 2 120 5.4 Included RBF6036
42" RM604204 Qty. 3 Qty. 2 120 5.4 Included RBF6042
48" RM604804 Qty. 3 Qty. 2 120 5.4 Included RBF6048
54" RM605404 Qty. 3 Qty. 2 120 5.4 Included RBF6054
60" RM606004 Qty. 3 Qty. 2 120 5.4 Included RBF6060
66" RM606604 Qty. 3 Qty. 2 120 5.4 Included RBF6066
72" RM607204 Qty. 3 Qty. 2 120 5.4 Included RBF6072
* Lamps not included. Halogen are 50 watt, PAR 20; heat lamps are 250 watt, infrared BR40.
+ Optional backsplash is recommended when using infrared heat lamps.
++ Hood amps without blower; for total system amps combine hood and blower amps.
Ten HVI certified, ducted blower options
INTERNAL EXTERNAL*
EXTERIOR IN-LINE
CFM (H/V) Model CFM Model CFM Model
900/850 P8** 1500 336 1100 HLB11
500/460 P5 1200 335 800 HLB9
900 332H 600 HLB6
600 331H 280 HLB3
NOTE: Purchase blower separately. See pages 42 and 43.
* External blower models require Rough-In Kit model 332KR.
** Not for use with 30" hood.
Options Selection Table
RM60000 & 64000
BACKSPLASH
RM60000 SERIES
SOFFIT CHIMNEY
64000 BAFFLE
FILTERS
RM60000 BAFFLE
FILTERS
WIDTH STAINLESS
STEEL
STAINLESS
STEEL
STAINLESS
STEEL
STAINLESS
30" RMP3004* RMN3004 RBF30 RBF6030
36" RMP3604* RMN3604 RBF36 RBF6036
42" RMP4204* RMN4204 RBF42 RBF6042
48" RMP4804* RMN4804 RBF48 RBF6048
54" RMP5404 RMN5404 NA RBF6054
60" RMP6004 RMN6004 NA RBF6060
66" RMP6604 RMN6604 NA RBF6066
72" RMP7204 RMN7204 NA RBF6072
* Works with 64000 Series.
