Broan 61000EX - Manual (Page 21)

21
P
ower
Packs
• The Hideaway offers clean cabinet
lines, effective ventilation and
over-the-range storage.
• Accommodates 30" wide by
24" to 30" high face frame cabinets.
• Fluorescent cooktop lighting
(lamps sold separately).
• Powerful, quiet 360 CFM/4.5 sone
performance (vertical discharge
only).
• Blower and light automatically turn
on when hood is pulled out.
• Heat Sentry ™ detects excessive
heat and adjusts blower speed to
high automatically.
• Designed for ducted (vertical
discharge only) installations.
Includes 3 1 ⁄
4
" x 10" damper adapter.
• Must order Rough-In Kit model
113123 for installation,
purchase separately.
• Fits into custom cabinetry from
30" to 42" wide.*
• Powerful, quiet 360 CFM/5.0
sone performance (vertical
discharge only).
• 24" fluorescent tube lighting
(bulb not included).
• Heat Sentry ™ detects excessive heat
and adjusts blower speed to high
automatically.
• For ducted installations, includes
damper/adapter for 3 1 ⁄
4
" x 10" duct.
• Must order model 103123 Rough-In Kit.
MODEL PM 25WW, PM 25BL
• Two-speed motor with rocker
switches.
• 250 CFM fan (vertical discharge).
• Enclosed light (bulb not included).
• Washable aluminum filter.
• Black or White finish.
• Built-in 7" round duct adapter.
• Optional non-ducted kit, Model
354NDK (purchased separately).
MODEL PM 44WW, PM 44BL
• Variable speed, rotary controls.
• Twin squirrel-cage blower, 410 CFM
(vertical discharge).
• Two-level light control
(bulb not included).
• Two washable aluminum filters.
• Black or White finish.
• For ducted installations, includes
damper/adapter for 3 1 ⁄
4
" x 10" duct.
• Optional non-ducted kit, Model 355
NDK (purchased separately).
Range Hood Specifications Options & Accessories
ROUGH-IN FLUORESCENT EXTENSION
MODEL VOLTS AMPS SONES CFM DUCT KIT BULB KIT
103023** 120 3.7 5.0 360 3 1 ⁄
4
" x 10" 103123 F20T12 97009790
Fluorescent Tube: 24", F20T12 (not included).
* For installations up to 36" order extension kit No. 97009790.
** Duct vertical only.
Range Hood Specifications Accessory
ROUGH-IN FLUORESCENT
MODEL VOLTS AMPS SONES CFM DUCT KIT BULB
113023 120 3.7 4.5 360 3¼" x 10" 113123 F20T12
Fluorescent Tube: 24", F20T12 (not included). Duct vertical only.
Power Pack and Power Module Specifications Options & Accessories
NON-DUCTED ALUMINUM CHARCOAL
SILVER WHITE BLACK VOLTS AMPS SONES CFM DUCT KIT + FILTER FILTER 30" LINERS 36" LINERS
PM390 – – 120 2.9 6.0 390 6" RD 357NDK B08087922 B08999040 LT30 or LB30 LT36 or LB36
PM250 – – 120 2.1 8.0 250 7" RD 356NDK B08087922 B08999040 LT30 or LB30 LT36 or LB36
– PM44WW PM44BL 120 4 5.5 410 3¼" x 10" 355NDK R610080 R610081 – –
– PM25WW PM25BL 120 2.5 7 250 7" RD 354NDK R610027 R610049z – –
+ Includes charcoal filter. Some duct work is required for non-ducted applications.
MODEL PM390
• Silver paint finish.
• Three speed, slide control.
• Heat Sentry
™ detects excessive heat
and adjusts speed automatically.
• Quiet centrifugal blower, 390 CFM
(vertical discharge).
• Dual 40-watt lamps (Purchase
separately).
• Dishwasher safe aluminum filter.
• For ducted installations, includes
adapter and damper for 6" round duct.
• Optional non-ducted filter kit
(Purchase separately).
• Works with optional custom hood
liners in 30", 36", “Box” or “T” design.
MODEL PM250
• Silver paint finish.
• Two speed motor, rocker control.
• Efficient 250 CFM fan (vertical
discharge).
• Dual 40-watt lighting (Purchase
lamps separately).
• Dishwasher safe aluminum filter.
• For ducted installations, built-in
adapter for 7" round duct.
• Optional non-ducted filter kit
(Purchase separately).
• Works with optional custom hood
liners in 30", 36", “Box” or “T” design.
