SERIES CAT.
PAGE
DESCRIPTION FINISHES
(may not be
in all widths)
LIGHTING
(not included
unless stated)
CONTROL
FEATURES
CONTROL
TYPE
AIR-MOVER TYPE WIDTH
(inches)
MOUNT
TYPE
SERIES MOUNTING
HEIGHT*
VISIBLE
SHELL HEIGHT
(inches)
CEILING
HEIGHT
MAX
BULB
INCLUDED
DUCT FILTERS
INCLUDED
CFM/SONES
VERT. RECT.
CFM/SONES
HORIZ. RECT.
CFM/SONES
VERT. ROUND
HVI
CERTIFIED
HIGH PERFORMANCE HOODS HIGH PERFORMANCE HOODS
E60000 22, 23
Professional Style Hood
Choice of Internal &
External Blowers
SS
Halogen 50W
Lamps 2/3
Variable speed
Heat Sentry ™
Power-on LED Indicator
Rotary Centrifugal Blower 30, 36, 42, 48, Wall E60000 24"–30" 18 8' no
See Selected
Blower Below ††††
SS & Aluminum
Optional SS Baffle
Internal Blowers
600 to 1200.
Exterior or In-Line
Blowers 280 to 1500
Internal Blowers
600 to 1200.
Exterior or In-Line
Blowers 280 to 1500
— Y
E64000 22, 23
Professional Style Hood
Choice of Internal &
External Blowers
SS
Halogen 50W
Lamps 2/3
Variable speed
Heat Sentry ™
Power-on LED Indicator
Rotary Centrifugal Blower 30, 36, 42, 48 Under Cabinet E64000
20"–30"
electric***
24"–30"
gas
10 na no
See Selected
Blower Below ††††
Aluminum
Optional SS Baffle
Internal Blowers
600 to 1200.
Exterior or In-Line
Blowers 280 to 1500
Internal Blowers
600 to 1200.
Exterior or In-Line
Blowers 280 to 1500
— Y
E661 26 Range Hood
SS, WH, BL
42" SS only
Dual 50W
3 speed+boost, Delay-off,
Heat Sentry ™
Electronic Push High flow wheel 30, 36, 42 Under Cabinet E661 24"–30" 5 1 ⁄
8
na no 3 1 ⁄
4
" x 14" (V, H)
MicroMesh
Aluminum
120/0.4
290/2.5
550/8.5
130/<0.3
310/2.5
600/8.5
— Y
RM60000 24, 25
Professional Style Hood
Choice of Internal &
External Blowers
SS
Halogen 50W Dual
Heat Lamps 2/3
Variable speed
Heat Sentry ™
Two-Level Light
Rotary Centrifugal Blower
30, 36, 42, 48,
54, 60, 66, 72
Wall RM60000 24"–30" 18 8' no
See Selected
Blower Below ††††
SS & Aluminum
Optional SS Baffle
280 to 1500 See
Md# RM325H,
RM326H, Exterior
or In-Line Blowers
280 to 1500 See Md#
RM325H, RM326H,
Exterior or In-Line
Blowers
— Y
64000 24, 25
Professional Style Hood
Choice of Internal &
External Blowers
SS
Halogen 50W Dual
Heat Lamps 2/3
Variable speed
Heat Sentry ™
Two-Level Light
Rotary Centrifugal Blower 30, 36, 42, 48 Under Cabinet 64000
20"–30"
electric***
24"–30" gas
10 na no
See Selected
Blower Below ††††
Aluminum
Optional SS Baffle
280 to 1500 See Md#
P5, P8 External or
In-Line Blowers
500 or 900 See
Md# P5, P8
— Y
E662/E662E 27 Range Hood
SS, WH, BL
42" SS only
Halogen Dual 50W
3 speed+boost,
Selectable Delay-off,
Heat Sentry ™
I-Control ™
Touch Sensitive
Centrifugal Blower 30, 36, 42 Under Cabinet E662/E662E 24"–30" 5 1 ⁄
8
na no 10" round (V)
MicroMesh
Aluminum
180/0.3
460/5.0
750/9.0
160/0.8
480/4.0
890/9.0
For E662E See
Exterior or
In-Line Blowers
280 to 1500
Y
CHIMNEY HOODS CHIMNEY HOODS
RM50000 14, 15 Chimney Hood SS
Incandescent Dual 40W
(included)
Multi-speed
Heat Sentry ™
Slide Centrifugal Blower 30, 35 7 ⁄
16
Wall RM50000 24"–30" 11 1 ⁄
16
8'–9'
Opt. 10'
yes 6" round (V) Aluminum — — 270/6.5 Y
RM51000 14, 15 Chimney Hood SS
Halogen Dual 20W
(included)
Multi-speed
Heat Sentry ™
Slide Centrifugal Blower 35 7 ⁄
16
Wall RM51000 24"–30" 5 1 ⁄
16
8'–9'
Opt. 10'
yes 6" round (V) Aluminum — — 370/7.0 Y
RM52000 14, 15 Chimney Hood SS
Halogen Dual 20W
(included)
Multi-speed
Heat Sentry ™
Slide Centrifugal Blower 30, 36, 42 Wall RM52000 24"–30" 5 1 ⁄
16
8'–9'
Opt. 10'
yes 6" round (V) Aluminum — — 370/7.0 Y
RM53000 13 Chimney Hood SS
Halogen Dual 20W
(included)
Multi-speed
Heat Sentry ™
Slide Centrifugal Blower 30, 36, 42 Wall RM53000 24"–30" 3 1 ⁄
8
8'–9'
Opt. 10'
yes 6" round (V) Aluminum — — 370/7.0 Y
E54000 12 Island Chimney Hood SS
Halogen Quad 20W
(included)
Multi-speed
Heat Sentry ™
Slide Centrifugal Blower 35 7 ⁄
16
" x 27 9 ⁄
16
" Ceiling E54000 24"–30" 3 7 ⁄
8
8'–9'
Opt. 10'
yes 6" round (V) Aluminum — — 480/9.5 Y
E55000 11 Chimney Hood SS
Halogen Dual 20W
(included)
Push Button Slide Centrifugal Blower 35 7 ⁄
16
Wall E55000 24"–30" 2 1 ⁄
16
8'–9'
Opt. 10'
yes 6" round (V) Aluminum — — 360/6.5 Y
61000 7 Chimney Hood SS
Halogen Dual 20W
(included)
3 speed
Heat Sentry ™
Slide Centrifugal Blower 30, 35 7 ⁄
16
, 48 Wall 61000 24"–30" 9 3 ⁄
8
8'–9' yes
6" round (V)
30" & 35 1 ⁄
2
" Width
8" round (V) 48" Width
Non-ducted
Stainless Steel — —
450/9
900/9.5
Y
61000EX 7
Chimney Hood
External Blowers
SS
Halogen Dual
or Quad 20W
(included)
Variable Heat Sentry ™ Slide Centrifugal Blower 35 7 ⁄
16
, 48 Wall 61000EX 24"–30" 9 3 ⁄
8
8'–9' yes 8" round (V) Stainless Steel — —
280 to 1500
See External or
In-Line Blowers
Y
62000 8 Chimney Hood SS with Glass
Halogen Dual 20W
(included)
Variable speed, Delay-
off, Filter Indicator
Heat Sentry ™
Electronic Push Centrifugal Blower 35 7 ⁄
16
Wall 62000 24"–30" 6 3 ⁄
8
8'–10' yes 6" round (V) Stainless Steel — — 450/8.5 Y
63000 9 Island Chimney Hood SS
Halogen Four 20W
(included)
3 speed
Heat Sentry ™
Slide Dual Centrifugal Blower 39 3 ⁄
8 x
27 5 ⁄
8
Ceiling 63000 24"–30" 10 1 ⁄
4
8'–9' yes 8" round (V) Stainless Steel — — 900/9.5 Y
63000EX 9
Island Chimney Hood
External Blowers
SS
Halogen Dual
or Quad 20W
(included)
Variable Heat Sentry ™ Slide Centrifugal Blower 39 3 ⁄ 8 x 27 5 ⁄ 8 Ceiling 63000EX 24"–30" 10 1 ⁄ 4
8'–9'
Opt. 10'
yes 8" round (V) Stainless Steel — —
280 to 1500
See External or
In-Line Blowers
Y
RM65000 10 Chimney Hood SS
Halogen Dual 20W
(included)
Variable speed, Delay-
off, Filter Indicator
Heat Sentry ™
Electronic Push Centrifugal Blower 35 7 ⁄
16
Wall RM65000 24"–30" 11 13 ⁄
16
8'–9' yes 6" round (V) Aluminum — — 450/9.0 Y
BLOWERS BLOWERS
P5 43
Internal Blower
for 64000 and RMIP
na na na na Centrifugal Blower na Internal to Hood P5 na na na na 3 1 ⁄
4
" x 10" (V, H) na 460/10.5 500/10 – Y
P8 43
Internal Blower
for 64000 and RMIP
na na na na Dual Centrifugal Blower na Internal to Hood P8 na na na na 3 1 ⁄
4
" x 14" (V, H) na 850/10.5 900/10 — Y
RM325H 42, 43
Internal Blower
for RM60000
na na na na Dual Centrifugal Blower na Internal to Hood RM325H na na na na 7" round (V, H) na — — 600/6.0 Y
RM326H 42, 43
Internal Blower
for RM60000
na na na na Dual Centrifugal Blower na Internal to Hood RM326H na na na na 4 1 ⁄
2
" x 18 1 ⁄
2
" (V, H) na 1200/12 1200/12 — Y
331H 42, 43 ††† Exterior Blower na na na na Centrifugal Blower na
Roof or
Outside Wall
331H na na na na 10" round na — — 600/na Y
332H 42, 43
††† Exterior Blower
including 28000
na na na na Centrifugal Blower na
Roof or
Outside Wall
332H na na na na 10" round na — — 900/na Y
335 42, 43 ††† Exterior Blower na na na na Centrifugal Blower na
Roof or
Outside Wall
335 na na na na 10" round na — — 1200/na Y
336 42, 43 ††† Exterior Blower na na na na Centrifugal Blower na
Roof or
Outside Wall
336 na na na na 10" round na — — 1500/na Y
HLB3 43 ††† In-Line Blower na na na na Centrifugal Blower na
Attached to
Framing
HLB3 na na na na
Inlet 8" or 10" round
Outlet 8" round
na — — S 280(H)/ S 260(V) Y
HLB6 43 ††† In-Line Blower na na na na Centrifugal Blower na
Attached to
Framing
HLB6 na na na na
Inlet 10" round
Outlet 10" round
na — — S 600(H)/ S 600(V) Y
HLB9 43 ††† In-Line Blower na na na na Centrifugal Blower na
Attached to
Framing
HLB9 na na na na
Inlet 10" round
Outlet 10" round
na — — S 800(H)/ S 700(V) Y
HLB11 43 ††† In-Line Blower na na na na Centrifugal Blower na
Attached to
Framing
HLB11 na na na na
Inlet 10" round
Outlet 10" round
na — —
S 1100(H)/
S 1000(V)
Y
* Mounting Height is measured from the top of the cooktop to the bottom of the Hood. Except for
QS Series which is measured from the top of the hood to the top of the cooktop.
** Visible height of Chimney when in the raised position.
*** Minimum Height is 24" when using optional RMP series backsplash.
† SS=430 Stainless Steel, BL=Black on Black, AL=Almond w/Black Trim, AA=Almond on Almond,
BT=Bisque/Biscuit w/Black Trim, BC=Bisque/Biscuit on Bisque/Biscuit, WW=White on White,
WH=White w/Black Trim.
††† External blower for E60000, RM60000, E64000, 64000, 61000EX, 63000EX, RMPE, RMIP,
RMDDEX and E66000 Series.
†††† E60000, RM60000, E64000, 64000 or RMIP Series require 332KR Rough-In Kit when used
with Exterior or In-Line blowers.
s Performance ratings assume use of 10" round transition provided with blowers.
Note: “Bisque/Biscuit” is a new color name for “Biscuit.” The actual color remains unchanged.
Specif
ications
Range Hood Specifications
Discontinued
February 2009
Discontinued
February 2009
Discontinued
December 2008
Discontinued
February 2009
Discontinued
December 2008
Discontinued
December 2008
