Broan 61000EX - Manual (Page 16)

16
RMDDRBK Remote Control
Optional remote control will activate
downdraft from an alternate location.
Broan Elite RMDD Downdraft System
Ready where and when you need it. Rises to new heights to
meet the needs of high-end commercial style cooking.
• Compact design is installed directly
behind the cooktop for an unobtrusive
appearance. Thin profile saves precious
space under the cabinet.
• Chimney rises over 9 1 ⁄
2
" when activated,
ideal for large pots and pans.
• Infinitely adjustable control is designed
to provide convenient access to govern
the blower speed for effective and
quiet operation.
• Optional remote control will activate
downdraft from an alternate location.
• Heat Sentry ™ detects excessive heat
and adjusts blower speed to high
automatically.
• Dishwasher-safe filters are easy to
remove and feature a stylish brushed
stainless steel appearance for a
professional look.
• These units are not for installations
behind ovens.
• Internal 500 CFM centrifugal blower or
choice of eight External blower options:
four Exterior blowers from 600 to 1500
CFM, or four In-Line blowers from 280 to
1100 CFM. See page 43.
• Unique ducting capability allows the
internal or remote blower connection to
be ducted to the left, right or downward.
Do
wndrafts
Rangemaster
Range Hood Specifications Optional Accessory
BLOWER BLOWER REMOTE
WIDTH INTERNAL EXTERNAL † BUTTON KIT
30" RMDD3004 RMDD3004EX RMDDRBK
36" RMDD3604 RMDD3604EX RMDDRBK
48" RMDD4804 RMDD4804EX RMDDRBK
† External and In-Line blowers sold separately.
System Specifications
BLOWER VOLTS AMPS CFM DUCT
INTERNAL 120 4 500 3¼" x 10"
EXTERNAL † 120 6 — 3¼" x 14"
