min 30" - max 45"
22-7/8"
15
Chimne
y
Hoods
Range Hood Specifications Options & Accessories
STAINLESS FLUE NON-DUCTED NON-DUCTED
WIDTH STEEL VOLTS AMPS CFM DUCT EXTENSION* FLUE EXTENSION KIT+ FILTER
30" RM523004 120 3.1 370 6" RD RFX5204 RFXN5204 RRK51 FILTERSQUARE
36" RM523604 120 3.1 370 6" RD RFX5204 RFXN5204 RRK51 FILTERSQUARE
42" RM524204 120 3.1 370 6" RD RFX5204 RFXN5204 RRK51 FILTERSQUARE
* Optional flue extension for 10' ceiling—extensions over 10' have up to a 14-week order time.
+ Includes non-ducted filter.
• Multi-speed slide control.
• Heat Sentry
™ detects excessive heat
and adjusts blower speed to high
automatically.
• Two 20-watt halogen lamps included
(one level).
• Dishwasher-safe aluminum filters
feature a quick-release latch and
professional-style appearance.
• Ducted/non-ducted telescopic flue
accommodates ceiling heights from
8 to 9 feet. Extension flues for
higher ceilings are also available
for ducted and non-ducted applications.*
• Requires separate purchase of a
non-ducted kit (RRK51) for indoor
exhaust recirculation.
• Install hood so that the bottom of
the unit is 24 to 30 inches above the
cooking surface. Mounting height is
determined by ceiling height.
• Multi-speed slide control and
integrated dual light assembly.
• Heat Sentry ™ detects excessive heat
and adjusts blower speed to high
automatically.
• Dual 40-watt incandescent
lamps included (one level).
• Dishwasher-safe aluminum filter
features a quick-release latch and
professional style appearance.
• Includes non-ducted kit and charcoal
filter for indoor exhaust recirculation.
• Ducted/non-ducted telescopic
flue accommodates ceiling heights
from 8 to 9 feet. Extension flues for
higher ceilings are also available.*
• Non-ducted flue extensions available in
stainless steel only. +
• Install hood so that the bottom of
the unit is 24 to 30 inches above the
cooking surface. Mounting height is
determined by ceiling height.
Range Hood Specifications Options & Accessories
STAINLESS FLUE NON-DUCTED
WIDTH STEEL VOLTS AMPS CFM DUCT EXTENSION* KIT+ FILTER
35 7 ⁄
16
" RM519004 120 3.1 370 6" RD RFX5104 RRK51 FILTERSQUARE
* Optional flue extension for 10' ceiling—extensions over 10' have up to a 14-week order time.
+ Includes non-ducted filter.
• Multi-speed slide control.
• Heat Sentry
™ detects excessive heat
and adjusts blower speed to high
automatically.
• Two 20-watt halogen lamps included
(one level).
• Dishwasher-safe aluminum filters
feature a quick-release latch and
professional-style appearance.
• Ducted/non-ducted telescopic flue
accommodates ceiling heights from
8 to 9 feet. Extension flues for
higher ceilings are also available
for ducted applications.*
• Requires separate purchase of a
non-ducted kit (RRK51) for indoor
exhaust recirculation.
• Install hood so that the bottom of
the unit is 24 to 30 inches above the
cooking surface. Mounting height is
determined by ceiling height.
Range Hood Specifications Options & Accessories
FLUE EXTENSION* + NON-DUCTED FLUE
STAINLESS EXTENSION AVALIABLE IN
WIDTH STEEL WHITE BLACK VOLTS AMPS CFM DUCT STAINLESS STEEL WHITE BLACK STAINLESS STEEL ONLY FILTER
30" RM503004 RM503001 RM503023 120 3.1 270 6" RD RFX5004 RFX5001 RFX5023 RFXN5004 FILTEREB40
35 7 ⁄
16
" RM503604 RM503601 RM503623 120 3.1 270 6" RD RFX5004 RFX5001 RFX5023 RFXN5004 FILTEREB40
* Optional flue extension for 10' ceiling—extensions over 10' have up to a 14-week order time.
