In-Situ Tube 300R Telemetry System - Manual (Page 37)

800-446-7488 37 www.in-situ.com
Functional Mode and Test - Modem, Settings and Tests Tab
The Modem, Settings and Tests tab configures and displays modem settings.
1 Activates the modem. Must be active to access the additional options below.
2 Verifies that there is a SIM card installed and whether it needs a PIN.
3 Shows the current operator.
4 Displays the signal quality at the current location.
5 Selects the current band, as shown in the "Band" section.
6 Deactivates the modem.
7 Verifies the communications between the SIM card and the network.
8 Shows what networks the SIM card functions on.
9 Disables the PIN code for the SIM card.
