In-Situ Tube 300R Telemetry System - Manual (Page 31)

800-446-7488 31 www.in-situ.com
The Connected Probes tab configures the type of probes connected and their
addresses.
1 Parameters Monitoring tab: configure parameters that trigger alarms.
2 Selects the probes that are connected to the Tube.*
3
Lists the address of each connected probe. No probe should have the same
address.
4 Writes settings to the Tube.
* Non-vented Tube models automatically list Probe 1 as Barometer with an address of
100. Do not change this setting. Other probes that have been configured to address 100
should be readdressed.
Probe Configuration - Parameters Monitoring Tab
The Parameters Monitoring tab configures thresholds for up to eight parameters that
trigger alarms. Non-vented Tube models automatically assign Probe 1 as the
barometer. Do not alter this setting.
