Do not pull on the antenna or setup connector.
Battery
Tube 300R systems have an internal lithium battery pack (PN 0062280) that is not
rechargeable. Batteries are installed but not connected prior to shipping.
To connect, disconnect, or change a battery pack, follow the steps below:
1. Ensure an antenna is attached to the unit.
Never connect or disconnect power to the unit without an antenna
attached.
2. Plug in or unplug the battery pack from the circuit board connection shown below.
Connecting the Tube to the Computer
1. Connect the setup cable to the communication port of the Tube and to the computer.
2. Download the ANT Tube Tool software from www.in-situ.com/telemetrysoftware
3. Install and open the ANT Tube Tool software.
4. Select the correct serial port. A serial-to-serial adapter is typically COM1. A USB-to-
serial adapter is typically a different COM number.
