Drawings 93
ITEM NO. QUANTITY
PART NO./ DESCRIPTION
COMMENTS
1
1
20223 Winch Mount Assembly
2
1
50224 Winch Assembly
3
1
59R Roller Assembly, Winch
4
1
20286 W inch Cover
5
4
20203 Spacer, Winch
6
2
806542-1_3.4-16 x 4.50 Hex Bolt
7
4
91074A036 Lock W asher Assembly, 3.4
8
2
806542_3.4-16 X 4.50lg. Soc. Hd. Cap Screw
9
6
806284_1.2-13 x 2.00lg. Hex Bolt
10
8
810703_1.2 Lock W asher
11
2
806244_1.2-13 x 1.0 Hex Bolt
12
2
2061-10-8S_10MORB x 8MJIC Fitting 45
13
1
2081-4-2S 1.4 x 1.8 H.P. Hex Bushing
14
1
2047-2-2S 2MNPTX2FNPT Fitting 90 Drg Swivel
100K-2GSR Winch Mount Assembly
100K-2GSR Winch Mount Assembly
