100K-2GSR Main Manifold Assembly
Drawings 109
ITEM
QTY.
PART NO./DESCRIPTION
COMMENTS
1
1
J1A Main Manifold
2
6
H6 Flow Control Sandwich Assembly
3
14
A25 5.32 x 1.4 PTC Elbow
4
1
H35 Sequence Valve
5
2
2062-10-10S_10MORB x 10MJIC Fitting 90
6
2
206209-10-10S_10MORB x 10MJIC Fitting 90 Ext.
7
1
206209-6-6S_6MORB x 6MJIC Fitting 90 Ext.
8
1
2062-6-6S_6MORB x 6MJIC Fitting 90
9
2
2216-1212S Adaptor, Hydraulic
10
2
9005912-12S_MORB Plug
11
1
A48 1.4 x 1.4 PTC Elbow
12
1
2082-4S_1.4 Pipe Plug
13
2
H6PRM2_Pressure Control Sandwich
14
1
V6APBCP_DO5_Assembly
15
1
V6SR_DO5_Assembly
16
1
V6ABT_DO5_Assembly
17
1
10280-1 DO5 P Breakout Manifold
18
1
A46 5.32 x 1.8 PTC Elbow
19
1
H4B Air Piloted 2-W ay Valve
20
1
2216-2-4S_-4MORB x-4FNPT Str. Adaptor
21
1
2047-2-2S 2MNPTX2FNPT Fitting 90 Drg Swivel
22
1
HOS-OIL_1.8MNPTx1.8MNPTx130 lg_1.8 Hose
23
1
H52S Directional Valve Assembly
24
1
H92S Directional Valve Assembly
25
2
H93S Directional Valve Assembly
26
3
900598-4S_MORB Plug
27
4
DO5 O Ring, Viton
28
8
D03 O Ring, Viton
29
2
H7 Pilot Check Sandwich Assembly
30
2
H53S Directional Valve Assembly
31
1
900598-8S_MORB Plug
32
3
202702-8-8S_-8MORB x -8MJIC Str. Adaptor
33
2
202702-6-8S_-6MORB x -8MJIC Str. Adaptor
34
6
202702-6-4S_-6MORB x -4MJIC Str. Adaptor
35
2
202702-6-6S_-6MORB x -6MJIC Str. Adaptor
36
1
2081-4-2S 1.4 x 1.8 H.P. Hex Bushing
37
1
A47 3.16 x 1.8 PTC Elbow
