Page 135
Drawings 133
ITEM NO. QTY THIS ASSY.
PART NO./ DESCRIPTION
COMMENTS
1
1
2560-AS.BS Barrel, Spinner Grip
AS-Top/BS-Bott.
2
1
5A049A Rod, Spinner Grip
3
1
70017 Piston, Spinner Grip
4
1
25000 Seal Retainer, Spinner Grip
5
1
SL Stover Nut 3.4-16, Spinner Grip Cylinder
6
2
002-138 Piston Seal, Spinner Grip Cylinder
*
7
1
1870-1250-312B Rod Seal
*
8
1
SHD-1250 Rod W iper, Spinner Grip Cylinder
*
9
1
2-228-90 O Ring
*
10
1
8-228 Back Up, Spinner Grip Cylinder
*
11
1
2-016-90 O Ring, Spinner Grip Cylinder
*
12
2
1103K1 Grease Fitting, Straight
CYL25-AS Top, -BS Bottom Spinner Grip Cyl
CYL25-AS Top, -BS Bottom Spinner Grip Cyl
