A22 on board air filter assembly, Drawings 145 – Hawk Industries Hawkjaw Sr. Manual M100K-2GSR Serial Numbers 201 to 370 User Manual
Page 147
Drawings 145
ITEM NO. QUANTITY
PART NO./ DESCRIPTION
COMMENTS
1
1
A22 Top Cover, Air Filter
Not Spare part
2
1
A22 Base Top, Air Filter
Not Spare part
3
1
A22H Base Core, Air Filter
4
1
A22E Base, Air Filter
5
1
A22D Gasket, Air Filter
6
4
A22 Star Spacer, Air Filter
Not Spare part
7
2
A22B_C Filter Cartrige, Air Filter
8
4
A22F Corner Bolt, Air Filter
9
4
810557_3.16 Flat Washer
Not Spare part
10
1
A22A Float Drain, Air Filter
11
2
2089-4-4S_-4MNPT x-4FNPT Fitting 90 Elbow
12
1
2045-4-4S_-4MNPT x -4FNPT Fitting Str. Swivel
13
1
HOS-29_1.4MNPTx1.4MNPTx204lg_1.4 Hose
14
1
CP-20-B Male Quick Disconnect
15
1
C-20-B Female Quick Disconnect
16
1
A22I Indicator, Air Filter
A22 On Board Air Filter Assembly
A22 On Board Air Filter Assembly
