Cmor dome – Videoswitch CMOR D2 Dome User Manual
Page 7
CMOR Dome
Videoswitch Page
4
Vc601i.doc
1.2.2 Setting the dome address
• Set the 8-way switch (A) to the required address (camera number) of the dome as
per the table below. “0” represents OFF (down) and “1” represents ON (up).
8-way DIP switch
8-way DIP switch
Dome
Address 1 2 3
4 5 6 7
8
Dome
Address
1
2
3
4
5
6
7
8
not
used 0 0 0
0 0 0 0
0
16
0
0
0
0
1
0 0 0
1
1 0 0
0 0 0 0
0
17
1
0
0
0
1
0 0 0
2
0 1 0
0 0 0 0
0
18
0
1
0
0
1
0 0 0
3
1 1 0
0 0 0 0
0
19
1
1
0
0
1
0 0 0
4
0 0 1
0 0 0 0
0
20
0
0
1
0
1
0 0 0
5
1 0 1
0 0 0 0
0
21
1
0
1
0
1
0 0 0
6
0 1 1
0 0 0 0
0
22
0
1
1
0
1
0 0 0
7
1 1 1
0 0 0 0
0
23
1
1
1
0
1
0 0 0
8
0 0 0
1 0 0 0
0
24
0
0
0
1
1
0 0 0
9
1 0 0
1 0 0 0
0
25
1
0
0
1
1
0 0 0
10
0 1 0
1 0 0 0
0
26
0
1
0
1
1
0 0 0
11
1 1 0
1 0 0 0
0
27
1
1
0
1
1
0 0 0
12
0 0 1
1 0 0 0
0
28
0
0
1
1
1
0 0 0
13
1 0 1
1 0 0 0
0
29
1
0
1
1
1
0 0 0
14
0 1 1
1 0 0 0
0
30
0
1
1
1
1
0 0 0
15
1 1 1
1 0 0 0
0
31
1
1
1
1
1
0 0 0
