CMOR Dome
Videoswitch Page 27 Vc601i.doc
5.5 Camera
5.5.1 Main camera settings
5.5.1.1 Video Gain
The video gain may be set from 0 to 7 to compensate for losses in long cable runs. Default
is 0.
5.5.1.2 Video Lift
The high frequency video lift may be set from 0 to 8 to compensate for losses in long cable
runs. Default is 0.
5.5.1.3 Digital Zoom
This option selects whether you want to be able to zoom beyond the optical zoom limit and
use digital zoom. The default setting is OFF.
5.5.1.4 Day Settings (IR OFF)
These settings apply when the IR lamps are not on.
5.5.1.4.1 Shutter Speed
The shutter speed may be slowed down to achieve greater light sensitivity. Normally this
should be set to AUTO.
5.5.1.4.2 Exposure Compensation
5.5.1.4.3 Joystick Focus Mode
There are two settings; Auto & Manual. The default setting for DAY is AUTO.
5.5.1.4.4 Preset Focus Mode
There are two settings; Auto & Stored. The default setting for DAY is AUTO.
5.5.1.4.5 Zoom Limit
The zoom limit can be adjusted from1 – 100%
5.5.1.4.6 Backlight compensation
Backlight compensation can be turned ON or OFF
5.5.1.5 Night Settings (IR ON)
These settings apply when the IR lamps are on.
5.5.1.5.1 Shutter Speed
The shutter speed may be slowed down to achieve greater light sensitivity. For night time
operation it may be useful to change this from its default AUTO setting. Longer time periods
will cause blurring of moving images however.
5.5.1.5.2 Exposure Compensation
