4.4 Setting the alarm module baud rate
• Set sections 5 and 6 of the DIP switch as per the table below to select the required
baud rate. “0” represents OFF (down) and “1” represents ON (up).
• The default setting is 9600 baud (both switches OFF)
• PelcoD normally uses 2400 baud
• PelcoP normally uses 4800 baud
Baud rate 5 6
9600 0 0
2400 1 0
4800 0 1
19200 1 1
The alarm module baud rate should be set to be the same as the dome baud rate.
