CMOR Dome
Videoswitch Page
32
Vc601i.doc
6 Technical Data
6.1 Vi-D1 Classic and Vi-D2 Evolution Domes
6.1.1 Camera
Sony Ex-View Had ¼” CCD
18:1, 26:1 or 36:1 optical zoom and optional 12:1 digital zoom
6.1.2 IR
Illumination
Double-hetero AlGaAs LEDs
830nm wavelength (optional 940nm fully covert)
Degradation estimated at 3% per year (not guaranteed)
6.1.3 Power
requirements
24V DC, 2.5Amps Maximum
6.1.4 Physical
and
Environmental
Colour
Grey (custom colours may be ordered)
Operating Temperature
-35degC to 50degC
Environmental IP66
Dimensions/Weight
252.4mm x 485mm x 225.8mm (HxWxD), 4.32kg
Dimensions/Weight (Boxed)
385mm x 300mm x 300mm (HxWxD), 4.72kg
6.2 Vi-PSU-1 Power Supply
6.2.1 Power
requirements
Input
100 to 240 Vac 50/60Hz
Output 24Vdc,
2.5A
6.2.2 Physical
and Environmental
Environmental IP66
Dimensions/Weight
230mm x 140mm x 100mm (LxWxD), 1kg
Dimensions/Weight (Boxed)
340mm x 225mm x 140mm (LxWxD), 1.3kg
6.2.3 Safety
For safety reasons, the internal metal cover must not be removed. There are no user
serviceable parts inside.
