CMOR Dome

Videoswitch Page

Vc601i.doc

GND

CAM1*

GND

Camera input

RS485 (A)

RS485 (A) or (+) dome output

RS485 (B)

RS485 (B) or (-) dome output

Spare Not

connection

GND RS485

ground

Identification DVR

CAM2 (BNC)*

DVR camera input (dual camera version only)

CAM1 (BNC)*

DVR camera input

CAM2 (BNC)

Loop-through provided for test monitor (dual camera
version only)

CAM1 (BNC)

Loop-through provided for test monitor

*Note that the video connection(s) made be made either using the BNC or the screw
terminals, whichever is more convenient.
