5.6.6 Pan Limits
5.6.6.1 Use Pan Limits
If you wish to stop the dome from panning all the way round, for example if it is mounted on
a wall or corner, set this option (after you have set the right and left limits). Once set, the
dome will stop if it is panned up to a limit. When moving between presets, the dome will also
stay in the permitted zone rather than taking the shortest route as it would otherwise.
5.6.6.2 Set right limit
Enter this option and pan the dome to the right-most position that you want it to be able to
go to. Press SELECT (or wait 10 seconds) to set the position
5.6.6.3 Set left Limit
Enter this option and pan the dome to the left-most position that you want it to be able to go
to. Press SELECT (or wait 10 seconds) to set the position
5.6.7 Iris key usage
The Iris control keys on the keyboard may be used to either alter the:
Exposure compensation Brighten or darken the image
Shutter speed Provide integration and therefore more sensitivity in dark
conditions. Note that the shutter speed can only be
controlled in this way when the IR lamps are ON.
5.7 Presets
5.7.1 Set Preset
• To set a preset from within the menu, select this option using RIGHT.
• Use UP and DOWN to select a preset.
• Move the dome to the required position using the joystick.
• Wait 10 seconds or press the SELECT key.
• The new preset is not set
5.7.2 Preset Titles
Each preset may be given a title that is displayed every time it is called up. If no title is
entered, the display will show P1, P2, P3 etc
To create a camera title, move joystick/arrow key RIGHT to enter ‘input’ mode. Move
joystick/arrow keys UP/DOWN to select alphanumeric characters.
Move joystick/arrow keys LEFT to save & exit menu.
5.7.3 Preset Speed
The speed at which the dome moves to a preset is set here. The default setting is 60% of
full speed.
5.8 Tours
Tours are sequences of up to 100 presets that the dome moves between automatically,
dwelling for a period at each. The tour is repeated until interrupted by:
• Manual pan, tilt or zoom
