SRM Series/SRM-KIT Series Monitor
Page 66
ƒ USB Interface: If the touch screen interface connection is a USB connection,
connect the USB connector on the single board computer to the external USB
port connector of the SRM Series monitor.
7.3 Touch Panel Driver Installation
WARNING:
Before the touch screen driver is installed, make sure the system is
connected to the monitor with a USB cable or an RS-232 null cable.
Also, make sure the VGA connector on the system is connected to the
VGA connector on the bottom of the monitor.
To install the touch panel driver for the SRM Series, please follow the instructions below:
Step 1: Connect the SRM Series monitor to the single board computer. See above.
Step 2: Install the driver CD. Install the driver CD into the system to which the SRM
Series monitor is connected.
Step 3: Select the Touch Screen option in the menu of driver CD. The directory in
Figure 7-1 appears.
Figure 7-1: Setup Icon
