IEI Integration SRM_121_150 v2.02 - Manual (Page 21)

SRM Series/SRM-KIT Series Monitor
Page 11
1.3 Series Specifications
Table 1-3 shows the SRM Series specifications.
Model SRM-121 SRM-121XA/XMA SRM-150
LCD Size 12.1” 12.1” 15”
Input Interface Analog VGA and DVI-D
Resolution 800 x 600 1024 x 768 1024 x 768
Brightness 1000 cd/m
2
800 cd/m
2
Contrast 700:1 600:1
Display Color 262K (6 bit/color) or 16.7M (8 bit/color)
Pixel Pitch 0.3075 mm 0.240 mm 0.297 mm
Front Frame Aluminum
Chassis Heavy-duty steel
View Angle 130 (H)/120 (V) 120 (H)/120 (V) 150 (H)/110 (V)
Input Voltage 12VDC and 9~36VDC
OSD Function Yes
Mounting Wall / Panel / Rack / Arm / Stand
Color Silver
Dimension (mm) 340 x 260 x 58 409.62 x 309.0 x 65.2
Operating Temperature -10°C~60°C
Storage Temperature -20°C~80°C
IP Level IP 65 (SRM series only)
N/G Weight 4 kgs 6 kgs
Table 1-3: SRM Series Specifications
