Function Keys:
Confirm Key: To confirm the present operation.
Cancel Key: To cancel the present operation.
Selection Keys: To select the selections.
4.3.3. Comm Opt (Communication Options)
Function Path: Menu Options Comm Opt
Function Description:
BaudRate: Baud Rate is a measure of how fast data is moving between instruments
that use serial communication. In the FingerKey system, there are three selections
which is 9600, 38400 and 115200. Normally, for RS232 communication, the baud rate
has been recommended to set high (fast) baud rate; however, for RS485
communication, the baud rate has been recommended to set low (slow) baud rate.
Please according to the connecting device, use and buttons to
selection the baud rate properly.
Dev Num: Device Number, a machine number, setting range is from 0 to 255.
IP Address: Internet Protocol address, it is a unique number that devices use in order
to identify and communicate with each other on a computer network utilizing the
Internet Protocol standard (IP). The FingerKey default setting of IP address is
192.168.1.201. User may need to change this IP address according to practical
requirement. For more information about IP address setting please refer to the section
