MINIMUM HARDWARE RECOMMENDED
?16 MHz 386-SX or compatible
?28 mSec average access hard disk
?1:1 Interleave hard disk controller
?Mouse
?VGA display
ADAPTER INSTALLATION
Make sure the main power to your computer is OFF. You will need
a full-size, 16 bit/AT slot. If you are unfamiliar with the internal
design of your computer see its "Guide to Operations" manual for
step by step installation procedures.
Read JUMPER SETTINGS and for information about configuring
the adapter before plugging it into the slot.
JUMPER SETTINGS
These SX series adapters have four hardware jumpers. They are
JP1, JP2, JP3 and JP4, which are used for multiple board
operation. JP1 should be installed for a single board system.
NOTE: On the SX-7, jumper JP2 serves as the adapter selection
jumper. Adapter 1 is at the top, with adapter 4 at the bottom.
1
2
3
4
PLACE JUMPER HERE IF YOU HAVE ONLY ONE
ADAPTER
