Antex Electronics SX-26 Digital Audio Adapter User Manual
Page 20

17
Disk 2. The "DOS DRIVERS" disk contains DOS drivers and
applications:
?
SX25.EXE - DOS V3.3 TSR driver for the SX7, SX9,
SX11 SX-12a, SX20, SX22, SX23e and SX26
?
Z1.EXE - DOS V3.3 TSR driver for the Z1, Z1e, SX3,
SX33, SX33e
?
SX5E.EXE - DOS V3.3 TSR driver for the SX5e
?
ADG.EXE - Digital audio player/recorder
?
README.TXT (optional) - Additional information
WINDOWS DRIVER INSTALLATION
1. Insert the DRIVERS disk into your floppy drive (assumed to be
A:)
2. Start Windows
3. In Program Manager, click on File then Run..
4. Enter A:SETUP in the command line box, then press OK.
5. When the driver installation is complete, Windows should
restart automatically. If not, exit then restart Windows manually.
WINDOWS DRIVER CONFIGURATION
To change the adapter type, I/O address and interrupt settings of
the Windows driver:
1. Select Control Panel in the Main group of the Program Manager.
Then select Drivers.
