Test:
1. Desktop → IE browser → Enter the DDK-1700 IP address (as in the PPPoE settings in step
3 above) → DDK-1700 should load.
DDNS settings
1. Launch browser → Enter address to connect to DDK-1700 → Choose network → Enter
User name : ”root” and Password : ”Admin” → Click “OK” .
2. Select “DDNS” → Click “Enable DDNS” → Enter the “DDNS host name”, for example
“abc123. homeip.net” → Enter “DDNS Account”, for example “abc123” → Enter the “DNS
Password”, for example “7777” → Submit → The settings are now complete → Close
browser.
3. Re-open browser → Enter address,→ view DDK-1700 images. The procedure is complete.
NOTE: These settings are only for an ADSL Dynamic IP configuration. If your
configuration is fixed, it is not required to set the PPPoE and DDNS settings.
76
