White Balance
White balance corrects unnatural color shades. Select options “Auto”,
“Outdoor”, “Indoor”, “Fluorescent” and “Push Hold”.
Brightness:
Setting to compensate for backlighting.
Contrast:
Controls color intensity/strength.
Saturation:
Controls the strength of colors from black and white to bold.
Sharpness
Sets clarity of detail in images.
Timestamp Label:
Enter a timestamp label.
Timestamp Location: Click to choose location.
Submit:
Click to save settings.
NOTE: The default setting table of the exposure mode--
NTSC
Exposure Mode
Shutter Max Gain
Indoor 1/30~1/120 36 dB
Outdoor 1/30~1/750 36 dB
Night 1/30~1/500 12 dB
Moving 1/120~1/1,000 36 dB
Low noise 1/8~1/30 36 dB
PAL
Exposure Mode
Shutter Max Gain
Indoor 1/25~1/100 36 dB
Outdoor 1/25~1/750 36 dB
Night 1/25~1/500 12 dB
Moving 1/100~1/1,000 36 dB
Low noise 1/7.5~1/25 36 dB
31
