45
CD Indicators
5.5 Accessories
Description Ohaus Part No.
Adjustable Column 80250632
Wall Mounting Bracket 80250633
Scale Base Mounting Plate 80250634
RS232 Interface Cable/Printer 80500432
RS232 Interface Cable/PC 25 Pin 80500431
RS232 Interface Cable/PC 9 Pin 80500433
Printer AS142
5.6 Technical Data
Standard Equipment of CD-31 and CD-33 Indicators
• Indicator power input 9 V dc, 0.5 A
Materials
• Housing GE C6200 Cycoloy plastic.
• Keypad/display overlay polyester
Ambient conditions
The technical data are valid under the following ambient
conditions:
• Operating temperature -10°C to 45°C/14°F to113°F
• Storage temperature -40°C to 70°C/-40°F to158°F
• Relative humidity 10%.......95%, noncondensing
• Height above sea level up to 4000m
5.3 Service Information
If the Troubleshooting section does not resolve or describe your problem, you will need to contact an authorized Ohaus
Service Agent. For Service assistance in the United States, please call Aftermarket, Ohaus Corporation toll-free at
(800) 526-0659. An Ohaus Product Service Specialist will be available to help you.
5.4 Replacement parts
Description Ohaus Part No.
AC Adapter North America, 100-132 V ac, 60 Hz 80500435
AC Adapter Continental Europe, 196-253 V ac, 50 Hz 80500436
AC Adapter UK, 196-264 V ac, 50 Hz 80500437
This product is intended to be supplied by a UL Listed Direct-Plug-In Power unit marked "Class 2" and rated 9V dc, 500mA.
MODEL MODEL MODEL MODEL MODEL CD-31 CD-31 CD-31 CD-31 CD-31 CD-33 CD-33 CD-33 CD-33 CD-33
Capacity up to 199,999 (Lb or Kg)
Graduation lb/kg 0.0005 - 100
Displayed Resolution 1:10,000 LFT or 1:50,000 (Non LFT)
Weighing modes lb, kg, g
Functions weighing, parts counting, animal weighing, percent, checkweighing
Over range capacity Max capacity + 5 divisions
Stabilization time 1 to 4 seconds, depends on filter selection
Auto-zero tracking capture range OFF, 0.5, 1, or 3 divisions
Zeroing range 2%, 18%, or 100% of capacity
Internal resolution 1:400,000
Span calibration 10 to 100% of capacity
Load cell excitation voltage 5V dc
Load cell input sensitivity 2 or 3mV/V
Load cell drive 4 x 350 ohm cells
Display LCD 2 line; weight and prompt message
Power AC Adapter only
Keyboard 12 function keys 12 function + 11 numeric keys
Time and Date yes
Overall dimensions (WxDxH) in mm 254 x 19.68 x 7.92
Net weight 0.65kg
Shipping weight 0.95kg
Protection
• Not protected against dust and water.
• Installation category: Class III
