Kyocera KM-C1530 - Manual (Page 83)

Original Documents 4
KM-C1530 4-11
Manual Feeding (Sheet Documents)
To make copies using manual feeding (sheet documents)
1 Lift open the original cover, or the duplexing document feeder if it is
installed.
2 Position the document face down
onto the original glass.
? Does the object that is placed on
the original glass exceed the
maximum weight allowable?
➜ Do not place a document heavier
than 4-1/2 lbs. on the original
glass.
3 Align the corner of the document with
the arrow marks on the document
scales above and to the left of the
original glass.
4 Close the original cover, or the duplexing document feeder if it is
installed.
5 Select the desired settings.
? Do you need more information about the settings?
➜ Refer to “5 Basic Operations” and “6 Advanced Operations”.
6 Press the [Start] key to copy the document.
