8 Administrator Mode Operations
8-24 KM-C1530
When the necessary adjustments are finished, touch [Enter].
4 Using the black grids as references, check for shifts in cyan, magenta
and yellow.
5 In the Expert User’s Mode screen,
touch [Color Shift Correction] for the
color that you wish to adjust.
Touch [X], [Y] or [
θ
] for the adjustment
that you wish to make, and then touch
and to specify the desired
adjustment value.
Continue printing the test pattern and
making adjustments until there no
longer is a color shift. When the
necessary adjustments are finished, touch [Enter].
The example below shows the adjustment for cyan; however, the
other colors should be adjusted in the same way.
❍ If the lines are shifted in the X-
direction:
Touch [X], and then align on the
black grid.
