2 Before Making Copies
2-14 KM-C1530
Duplexing Document Feeder (Optional)
1
2
3 4
5
No. Part Name Description
1 Document output tray Collects documents that have been copied
2 Document guide Align one side of the document along the fixed document
guide, and then adjust the other guide to the width of the
document. See p. 4-4.
3 Document feed tray Load the documents to be copied face up. See p. 4-4.
4 Misfeed clearing cover
F1/F2 Opened when clearing a misfed document
5 Single-sheet feed tray Open to feed one sheet of the document at a time
