3.3 SCSI Select Utility Program
This utility is used on PCI/EISA models of the IBM PC Server line and allows the
user to:
• View and modify parameters for the SCSI controller
• View and modify parameters of SCSI devices
• Perform low-level formatting of attached SCSI hard disks
To access the SCSI Select Utility Program:
• Turn on the server and watch the screen
• When the message Press appears, press Ctrl and A
simultaneously.
A screen like the one in Figure 34 will appear.
┌───────── Adapter AHA-2940/AHA-2940W SCSISelect(Tm) Utility ──────────┐
│
│
│ │
│ Would you like to configure the host adapter, or run the │
│ SCSI disk utilities? Select the option and press │
│ │
│ Press to switch between color and monochrome modes │
│ │
│ │
│ │
│ ┌────────────── Options ───────────────┐ │
│ │ Configure/View Host Adapter Settings │ │
│ │ SCSI Disk Utilities │ │
│ └──────────────────────────────────────┘ │
│
│
│ │
│ │
│ │
└──────────────────────────────────────────────────────────────────────┘
Figure 34. IBM PC Server SCSISelect Utility Program - Main M e n u
• Press Enter to enter the Configure/View Host Adapter. option
A screen like the one in Figure 35 will appear.
┌───────── Configuration/View Host Adapter Settings ──────────┐
│ │
│ Configuration │
│ │
│ SCSI Bus Interface Definitions │
│ Host Adapter SCSI ID ........................ 7 │
│ SCSI Parity Checking ........................ Enabled │
│ Host Adapter SCSI Termination ............... Low ON/High OFF │
│ │
│ Additional Options │
│ SCSI Device Configuration ................... Press │
│ Advanced Configurations Options ............. Press │
│ │
│ - Reset to Host Adapter Defaults │
│ │
│ │
│ │
└──────────────────────────────────────────────────────────────────────┘
Figure 35. IBM PC Server SCSI Select Utility Program - Host Adapter Settings
