ITI-8000 Series LVD/SE SCSI
Cable Selection Guide
Cable Description BUS Length
Meters
Adapter
Connector
Device
Connector
Part
Number
Internal 68-pin ribbon, LVD
differential high density, 5
position (1 adapter & 4
devices) with built in LVD/SE
Terminator 16-Bit
LVD/SE
Internal
1.0 68-pin High
Density 68-pin High
Density 50-401030
External 68-pin high density
to 68-pin micro 16-Bit LVD
External
1.0 68-pin high
density
micro 68-pin high
density
male, rt.
angle 50-500175
External Adapter Cable, 68-
pin micro to 68 position high
density receptacle. 16-Bit LVD
External
0.2 68-pin micro 68-pin high
density
receptacle 50-500170
External 68-pin, high density,
one end right angle cable exit.
NOTE: Extends 50-500170 16-Bit LVD
External
2.0 68-pin High
Density 68-pin High
Density, rt.
Angle 50-500120
Table 5: ITI-8000 Series SCSI Cable Selection Guide
