Table 4: configuration headers and jumpers – IntraServer Technology ITI-90-100250 User Manual
Page 18
Page 18 of 83
Header Number
Function
HDR 1
Bus A Internal Termination Invert
HDR 3
Bus B Internal Termination Invert
HDR 4
Video Disable
HDR 5
Video Interrupt Disable
HDR 6
Bus A External Termination Invert
HDR 7
Bus B External Termination Invert
HDR 1002
Hot Swap Register Disable
J 6
Ethernet Port 0 Front/Rear Select
J 7
Ethernet Port 1 Front/Rear Select
J 8
Ethernet Port 2 Front/Rear Select
J 9
Ethernet Port 3 Front/Rear Select
J 11
Video Front/Rear
J 10
Video Front/Rear
Table 4: Configuration Headers and Jumpers
