Connecting to a Video Camera
The following illustration shows you how to connect the TV to a cam-
corder. Actual connections may vary according to the make and
model of the device. Refer to the user’s manual included with the
camcorder for more detailed instructions.
LINE OUT
AV2
DC-IN
ANT
S-VIDEO
VIDEO
R
L
AV1
LINE OUT
AV2
DC-IN
ANT
S-VIDEO
VIDEO
R
L
AV1
WB
S
B
R
W
Y
4-IN-1 cable
S-Video
Cables and connectors are
color-coded (black, red, white,
yellow).
AV2
connector
connectors
Note: When connecting the S-Video
connector and AV connectors at the
same time, the priority is given to the
S-Video connector.
