Harman-Kardon AVR 3650 - Manual (Page 52)

AVR
52
Appendix
Surround Mode Description Incoming Bitstream or Signal
DTS Neo:6
Mode Group DTS Neo:6 analog processing is available with DTS and DTS 96/24 signals and
two-channel analog or PCM signals to create a 3-, 5- or 6-channel presentation. See below
DTS Neo:6
Cinema Depending on the number of speakers in your system, select 3-, 5- or 6-channel
modes, enhanced for movie or video presentations. • DTS 2/2/.0 or .1, 3/2/.0 or .1
• DTS 96/24
• Analog (two-channel)
• PCM (32kHz, 44.1kHz or 48kHz)
DTS Neo:6
Music Available only in 5- and 6-channel modes, creates a surround presentation
suitable for music recordings. • DTS 2/2/.0 or .1, 3/2/.0 or .1
• DTS 96/24
• Analog (two-channel)
• PCM (32kHz, 44.1kHz or 48kHz)
Logic 7
Mode Group A HARMAN proprietary technology, Logic 7 technology enhances two-channel
and matrix-encoded recordings by deriving separate information for the surround
back channels. It provides more accurate placement of sound, improves panning
and expands the sound field, even when used with 5.1-channel systems.
Logic 7 technology uses 96kHz processing and is available in 5.1-or 7.1-channel
modes. Three variants are available. See below
Logic 7
Movie Especially suited to two-channel sources containing Dolby Surround or matrix
encoding, Logic 7 Movie mode increases center-channel intelligibility. The AVR is
programmed at the factory to default to this mode for two-channel signals. • Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
Logic 7
Music Logic 7 Music mode is well suited to conventional two-channel music recordings. • Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
Logic 7
Game Use Logic 7 Game mode to enhance enjoyment of video-game consoles. • Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
5-Channel Stereo Useful for parties, the left- and right-channel information is played through both
the front and surround speakers on each side, while the center speaker plays a
summed mono mix. • Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
7-Channel Stereo Expands the 5-Channel Stereo presentation to include the surround back channels. • Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
2-Channel Stereo Turns off all surround processing and plays a pure two-channel signal or a downmix
of a multichannel signal. The signal is digitized and bass management settings are
applied, making it appropriate when a subwoofer is used. • Analog (two-channel; DSP downmix available for multichannel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
Table A12 – Surround Modes – continued
